| Nominal Voltage (V) | 51.2 |
| Capacity (Ah) | 100 |
| No. of Cell in Series | 16 |
| No. of Cell in Parallel | 1 |
| Total No. of Cell | 16 |
| Cell Type | Prismatic |
| Chemistry | LFP |
| Electrical |
|---|
| Maximum cut-off voltage (V) | 57.6 (-1.6) |
| Minimum cut-off voltage (V) | 44.8 (+1.6) |
| Charging Voltage (V) | 56.0 |
| Charging Mode | CC-CV |
| Maximum charging current (A) | 40.0 |
| Maximum Continuous discharging current (A) | 100.0 |
| Cell over voltage Protection | 3.6 |
| Cell over voltage release | 3.5 |
| Cell under voltage Protection | 2.8 |
| Cell under voltage release | 2.9 |
| Cycle Life @0.3C/1C @25°C | 2000 |
| DOD Level (%) | 90% |
| Protection |
|---|
| Cell under voltage protection | Yes |
| Cell over voltage Protection | Yes |
| Over current protection | Yes |
| Short circuit protection | Yes |
| Temperature protection | Yes |
| Temperature |
|---|
| Working Temperature (°C) | 0-55°C |
| Storage Temperature (°C) | 0-45°C |
| Communications |
|---|
| Bluetooth For Mobile Application Showing Real Time Data. |
| RS485/ CAN Protocol Communication For Telematics. |
| Other |
|---|
| Dimension (mm) LxWxH | (415x285x263) |
| Weight (Kg) | 45 (Approx.) |
