| Model | GRE4850 | GRE48100 | GRE48200 | |||
|---|---|---|---|---|---|---|
| Specification | 48V50Ah | 51.2V50Ah | 48V100Ah | 51.2V100Ah | 48V200Ah | 51.2V200Ah |
| Combination | 15S1P | 16S1P | 15S1P | 16S1P | 15S1P | 16S1P |
| Capacity | 2.4kWh | 2.56kWh | 4.8kWh | 5.12kWh | 9.6kWh | 10.24kWh |
| Standard discharge current | 50A | |||||
| Max. discharge current | 100A | |||||
| Working voltage range | 40.5~54VDC | 43.2~57.6VDC | 40.5~54VDC | 43.2~57.6VDC | 40.5~54VDC | 43.2~57.6VDC |
| Standard Voltage | 48VDC | 51.2VDC | 48VDC | 51.2VDC | 48VDC | 51.2VDC |
| Max. charging current | 50A | 50A | 50A | 50A | 100A | 100A |
| Max. charging voltage | 54V | 57.6V | 54V | 57.6V | 54V | 57.6V |
| Cycle | 3000~6000 cycles @DOD 80% / 25℃ / 0.5C | |||||
| Working humidity | 65±20%RH | |||||
| Operating temperature | -10℃~+50℃ | |||||
| Working altitude | ≤2500m | |||||
| Cooling method | Natural cooling | |||||
| Installation | Cabinet/Rack Mount | |||||
| Protection level | IP20 | |||||
| Max of parallel | 15PCS | |||||
| Warranty | 5~10 Years | |||||
| Communication | Default: RS485/RS232/CAN | Optional: WiFi/4G/Bluetooth | |||||
| Certified | CE ROHS FCC UN38.3 MSDS | |||||
| Product Size | 440*495*88mm | 440*495*178mm | 440*590*178mm | |||
| Package Size | 555*500*130mm | 555*500*235mm | 480*650*220mm | |||
| Net weight | 25kg | 37kg | 41kg | 45kg | 101kg | 105kg |
| Gross weight | 30kg | 42kg | 49kg | 56kg | 111kg | 115kg |
*Voltage, capacity, size/color customization, OEM/ODM services can be provided according to customer needs
