Utility Scale ESS
| Product Model | GRE-EL3000P2-DC | GRE-EL4000P2-DC | GRE-EL5000P2-DC |
|---|---|---|---|
| Battery Side | |||
| Cell Capacity | 280Ah | 280Ah | 314Ah |
| Cell Configuration | 9P384S | 11P432S | 13P384S |
| Nominal Voltage | 1228.8V | 1382.4 | 1228.8V |
| Operating Voltage Range | 1164.8 V - 1497.6 V | ||
| Nominal Capacity | 3096.57kWh | 4257.832kWh | 5015kWh |
| Supported Charge & Discharge Rate | < 0.5C | ||
| Protection | |||
| Over-voltage Protection | Yes | ||
| Over-current Protection | Yes | ||
| Short-circuit Protection | Yes | ||
| Over-temperature Protection | Yes | ||
| General Data | |||
| Max. Efficiency | > 94% (Excluding self consumption) | ||
| Operating Temperature Range | -20 to 50°C | ||
| Operating Humidity Range | 0 ~ 95%RH | ||
| Noise | < 75DB | ||
| Dimensions (W*H*D) | 2850*2896*6058 | 2850*2896*6058 | 2850*2896*6058 |
| Weight | 32T | 42T | 52T |
| Protection Degree | IP55 | ||
| Cooling Method | Liquid Cooling | ||
| Fire Protection Method | Perfluoro+Pack-level+Active Firewarning | ||
| Max. Operating Altitude | ≤ 2000m | ||
| Networking Mode | LAN | ||
